Colour Orange
Frame FORM™ Alloy // Full Sealed Cartridge Bearings // RIDE-4™ Adjustable Geometry // FORM™ Alloy Rear Triangle
Fork RockShox Recon Gold 130mm // 27.5 = 37mm Offset // 29 = 42mm Offset // 130mm Travel
Shock RockShox Deluxe Select+ // Sealed Bearing Eyelet // 25x8mm Frame Hardware // All Sizes = 190x45mm // 120mm Rear Wheel Travel
Handlebar Rocky Mountain AM // 780mm Width // 25mm Rise // 9° Backsweep // 5° Upsweep // 31.8 Clamp
Grips Rocky Mountain Lock On Light
Stem Rocky Mountain 31.8 XC // 5° Rise // All Sizes = 50mm
Seatpost Rocky Mountain Toonie Drop Composite 30.9mm // XS-SM = 125mm // MD = 150mm // LG-XL = 170mm
Saddle WTB Volt 142
Pedals NA
Shifters Shimano Deore, 12 speed
Front Derailleur NA
Rear Derailleur Shimano Deore
Brakes Shimano MT4100 2 Piston // Resin Pads // Shimano RT30, [F] 180mm [R] 180mm
Cassette Shimano Deore 10-51T, 12 speed
Chain Shimano M6100
Crankset FSA Comet MegaExo HD // 32T // 24mm Spindle // XS = 165mm, SM-XL = 170mm
Bottom Bracket FSA BB92 24mm
Rims WTB ST Light i27 TCS 2.0 Tubeless // 28H // Tubeless Compatible - Tape // Valves
Hubs [F] Shimano MT410, 15mm Boost // [R] Shimano MT410 Boost 148mm
Spokes 2.0 Stainless
Tyres [F] Maxxis Rekon 2.4 WT EXO Tubeless Ready // [R] Maxxis Rekon 2.4 WT EXO Tubeless Ready
Extra FSA Orbit NO.57E // 36°x45° Bearings // 30.2mm x 41mm x 7.1mm Upper // 40mm x 51.8mm x 7.5mm Lower // 1.5” Crown Race
Notes We make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification.
